Contact USTwo-Piece Aluminium Batten System Installation Guide
1. Apply the Two-Piece Batten Base to the supporting structure and fix it as required.
If the batten is to be installed close to flush to an end surface, ensure at least 5mm of clearance is provided to allow the batten
cover to click over the base. To ensure a straight, consistent, and parallel installation, it is strongly recommended that a level be
used to position each base.
Centre Fixing
Fix with fasteners through the centre location groove.
Dual Fixing
Fix with fasteners at two appropriately spaced locations.
2. Install additional Two-Piece Bases and fix them as required.
To ensure equal and consistent spacing between each batten, space the bases according to your desired finished spacing using the following formula:
For 50mm Battens:
X (spacing between bases) = Desired finished spacing + 4mm
Y (centre-to-centre spacing) = Desired finished spacing + 50mm
For 40mm battens:
X (spacing between bases) = Desired finished spacing + 4mm
Y (centre to centre spacing) = Desired finished spacing + 40mm
For 25mm Battens
X (spacing between bases) = Desired finished spacing + 4mm
Y (centre-to-centre spacing) = Desired finished spacing + 25mm
3. Install additional Two-Piece Batten Covers and fix them as required.
Click the cover over each of the bases, ensuring a tight fit. Although the Batten product is designed to ensure a secure click fit, if extra security against dislodgement is required, follow the detail provided below.
Adhesive Fix
Prior to installation, apply a bead of adhesive to the internal face of the step in the cover and click it over the base. Ensure that the cover is secured in place until the adhesive sets.
LabelDescription
A Adhesive
Mechanical Fix
Apply screws or rivets as required through the cover and into the base.
